OUR PRODUCTS

Integrated Photonics

Integrated Photonics is all about our equipment for high-precision positioning of Photonic Integrated Circuits (PICs), enabling you to optimize your back-end processes and reduce your costs. Our fiber array unit combines the latest technologies on automatic fiber placement. Our Photonic Test Prober (PTP) and Photonic Visual Inspection Tool (PVIT) are part of the MEKOPP project.

Engineer working on an integrated photonics machine

Connecting the high-speed-data world of tomorrow

INTEGRATED PHOTONICS

Fiber Array Unit

Close up of a fiber being exposed for integrated photonics

Array V1000

Most commonly used Fiber array units apply V-groove substrates with a 250 µm or 127 µm pitch. The number of fibers (channels) depend on the application. Contact us to discuss your specific requirements on integrated photonics.

Photos in the slider below are a courtesy of LioniX and PhiX.

KEY BENEFITS
  • Cost effective
  • High reliability, high precision
  • Short production cycle time
  • Flexible set-up to produce a large range of FAUs
Fiber array of LioniX made by Hans Roggen
Fiber array of LioniX for integrated photonics
Fiber array for integrated photonics of PHIX
Fiber array for integrated photonics of PHIX

INTEGRATED PHOTONIC TEST PROBER

Photonic Test Prober

o/e Probing machine for Photonic Integrated Circuits

Sirius 600

Our Photonic Test Prober (PTP) supports fast, simultaneous PIC optical and electrical testing. Sirius is made for functional PIC testing.

Photo below is a courtesy of PI.

KEY BENEFITS
  • Fast optical alignment with fiber arrays
  • Easy to configure test rack to tailor DUT test demand with our PXi instrument approach
  • Using established semicon test technology (partner with Salland Engineering)
  • Up to 8 inch electrical probe card support
  • Fully automated probe calibration
Optical test probes on a photonic wafer

INTEGRATED PHOTONIC VISUAL INSPECTION

Photonic Visual Inspection

Silicon wafer inside a machine

Helios 600

Helios is designed to be compatible with the same base platform as Sirius. Our Photonic Test Prober. Helios provides you with multiple testing and metrology options when required. Also, as with Sirius, Helios is designed for high throughput. Ready to take you steps ahead to the future of Integrated Photonics.

KEY BENEFITS
  • Fast wafer level inspection using neural network supported algorithms
  • High and low resolution mode
  • Waveguide inspection, particle detection, residue detection
  • Compatible with 4, 6, 8 inch wafers
Photonics Wafers with different chips
Cameras performing automated optical inspection on a wafer
